products
150-600gsm base paper ,cardboard ,ivory board ,aluminum foil paper or others
Main technical datas
|
Type |
BJ-SGW500 |
|
Suitable material |
150-600gsm base paper ,cardboard ,ivory board ,aluminum foil paper or others |
|
Production speed |
150-200pcs/min (four workplaces) |
|
Plate specification |
5inch to 9inch ,，max paper unfold size：235mm |
|
Rated power |
14KW (include hydraulic ) |
|
Total weight |
1800KGS |
|
Overall dimension |
2560*1450*2100mm |
|
Power source |
380V, 50HZ |
|
Airsupply |
Air compression : 0.8mpa ,air out put : 0.3—0.6 cbm/ min |
